NA/NB Miata Alignments and Suspension Set-up

NA/NB Miata Alignments and Suspension Set-up

An alignment can make or break a car. Few things are as instantly gratifying as rolling off the rack with a new set-up that transforms the car! There is no one-size-fits-all when it comes to alignments, there are always trade-off. Set-ups that give better handling performance often have poor tire wear. a set-up that has great turn-in and cornering can be weaker in the braking department. As with all things in cars, it's about picking what's ideal for your application.

We've created a list of common baselines that we use here at our shop. each car and driver has preferences and needs that are unique, but this is a good starting point!

Leroy Engineering Recommended baseline alignments

Street Only

Front:

Camber: -1.0-2.0 degrees

Caster: 4-5 degrees

Toe:  1/8" IN

Rear:

Camber: -2.5 degrees

Toe : 1/8" IN



Aggressive Street /Occasional autocross or track

Front:

Camber: -3.2 degrees

Caster: 6-7 degrees

Toe:  1/8" IN

Rear:

Camber: -2.8 degrees

Toe : 1/8" IN



Autocross Street class

Front:

Camber: As much as you can get, usually around -1.5 degrees

Caster: 5-6 degrees

Toe: 0

Rear:

Camber: -2.5 degrees

Toe: 1/8" IN



Autocross Street-Touring and Modified classes

Front:

Camber: -4.0 degrees

Caster: 6-7 degrees

Toe:  0

Rear:

Camber: -3.2 degrees

Toe - 1/8" IN



When it comes to selecting your shocks, regardless of what brand or type you pick, you want a spring rate that matches your car's weight and application. Below is what we have found to be a good general rule based on an average Miata weight. However, if your car is heavier or lighter, and you're driving application is unique, you might need something different. As always, feel free to call us and we can advise you on what would be best for your set-up.

Most coilovers, including the Silver's we carry can be purchased and valves for any spring rate.

Recommended Spring Rates

Street Only - Focus on comfort

6 K Front, 5 K Rear (336 lb/280 lb)

Street/Occasional Autocross - Focus on spirited driving

8 K Front, 6 K Rear (448 lb/336 lb)

Autocross 200tw Aggressive

10 K Front, 8 K Rear (560 lb/448 lb)

Track, Stock HP, no aero

12-14 K Front, 8-10 K Rear (672-784 lb/448-560 lb)

Track, High HP, Aero

14-15 K Front, 12 K Rear (784-840 lb/672 lb)
